- Understand how the convolution equation is a consequence of linearity and time invariance.
- Practice computing convolutions using both the equation directly and the flip-and-shift (ticker tape) method.
- Begin to develop insight into how the optimal approach to computing a convolution depends on the signals being convolved.
YouTube Videos
LTI Systems and Convolution
Convolution Properties
Convolution Example - Flip and Shift
Convolution using Tickertape
Convolution with a Unit Step
Discrete-time Convolution Sum and Example
Summary
Convolution and LTI Systems
For discrete-time systems that are linear and time-invariant (LTI), the output \(y[n]\) can be expressed as the convolution of the input signal \(x[n]\) with the system’s impulse response \(h[n]\)
\[y[n] = x[n] * h[n]\]
where \(*\) denotes convolution.
Discrete-Time Convolution Equation
The discrete-time convolution sum is given by:
\[y[n] = \sum_{k=-\infty}^{\infty} x[k]\,h[n-k]\]
This equation follows directly from the properties of linearity and time invariance.
Flip-and-Shift (Ticker Tape) Method
An alternative way to compute convolution is the flip-and-shift method:
- Flip one of the signals (usually \(h[n]\)) to obtain \(h[-k]\).
- Shift the flipped signal by \(n\), giving \(h[n-k]\).
- Multiply point-by-point with \(x[k]\).
- Sum over all \(k\).
Figure 1.3.1: Example of the ticker-tape method of estimating the convolution between two discrete-time signals.
Choosing a Convolution Method
The most efficient way to compute a convolution depends on the characteristics of the signals involved:
- Finite-length signals often benefit from the flip-and-shift graphical approach.
- Signals with simple analytic expressions may be easier to compute directly using the convolution sum.
Properties
Commutative: The output (i.e., convolution) of an LTI system with input \(x[n]\) and unit impulse response \(h[n]\) is the same to the output of an LTI system with input \(h[n]\) and unit impulse response \(x[n]\)
\[x[n] * h[n] = h[n] * x[n]$$
Distributive: The output to \(x[n]\) convolved with two different unit impulse responses added together is the same to the output to \(x[n]\) convolved separately with each unit impulse response and then both convolutions added together after
\[x[n] * (h_1[n] + h_2[n]) = x[n] * h_1[n] + x[n] * h_2[n]$$
Figure 1.3.2: Flow diagram representing two parallel systems and their equivalent single systems
Associative: The output to \(x[n]\) convolved with two different unit impulse responses convolved together is the same to the output to \(x[n]\) convolved with either unit impulse response first, followed by that output being convolved with the other unit impulse response
\[x[n] * (h_1[n] * h_2[n]) = (x[n] * h_1[n]) * h_2[n] = (x[n] * h_2[n]) * h_1[n]$$
Figure 1.3.3: Flow diagram representing the associative property of convolution. Remember that the order of the LTI systems is irrelevant due to the commutative property.
