4.4: Durable Storage Revisited - Geographically Separated Replicas

Durable Storage and the Durability Mantra

Chapter 2 demonstrated how to create durable storage using a technique called mirroring, and Section 3.8 showed how to give the mirrored replicas the all-or-nothing property when reading and writing. Mirroring is characterized by writing the replicas synchronously—that is, waiting for all or a majority of the replicas to be written before going on to the next action. The replicas themselves are called mirrors, and they are usually created on a physical unit basis. For example, one common RAID configuration uses multiple disks, on each of which the same data is written to the same numbered sector, and a write operation is not considered complete until enough mirror copies have been successfully written.

Mirroring helps protect against internal failures of individual disks, but it is not a magic bullet. If the application or operating system damages the data before writing it, all the replicas will suffer the same damage. Also, as shown in the fault tolerance analyses in the previous two chapters, certain classes of disk failure can obscure discovery that a replica was not written successfully. Finally, there is a concern for where the mirrors are physically located.

Placing replicas at the same physical location does not provide much protection against the threat of environmental faults, such as fire or earthquake. Having them all under the same administrative control does not provide much protection against administrative bungling. To protect against these threats, the designer uses a powerful design principle:

The Durability Mantra

Multiple copies, widely separated and independently administered…

Multiple copies, widely separated and independently administered…

Another formulation of the durability mantra is "lots of copies keep stuff safe" [Suggestions for Further Reading 4.2.3]. The idea is not new: "…let us save what remains; not by vaults and locks which fence them from the public eye and use in consigning them to the waste of time, but by such a multiplication of copies, as shall place them beyond the reach of accident." \(^*\)

The first step in applying this design principle is to separate the replicas geographically. The problem with separation is that communication with distant points has high latency and is also inherently unreliable. Both of those considerations make it problematic to write the replicas synchronously. When replicas are made asynchronously, one of the replicas (usually the first replica to be written) is identified as the primary copy, and the site that writes it is called the master. The remaining replicas are called backup copies, and the sites that write them are called slaves.

The constraint usually specified for replicas is that they should be identical. But when replicas are written at different times, there will be instants when they are not identical; that is, they violate the specified constraint. If a system failure occurs during one of those instants, violation of the constraint can complicate recovery because it may not be clear which replicas are authoritative. One way to regain some simplicity is to organize the writing of the replicas in a way understandable to the application, such as file-by-file or record-by-record, rather than in units of physical storage such as disk sector-by-sector. That way, if a failure does occur during replica writing, it is easier to characterize the state of the replica: some files (or records) of the replica are up to date, some are old, the one that was being written may be damaged, and the application can do any further recovery as needed. Writing replicas in a way understandable to the application is known as making logical copies, to contrast it with the physical copies usually associated with mirrors. Logical copying has the same attractions as logical locking, and also some of the performance disadvantages, because more software layers must be involved and it may require more disk seek arm movement.

In practice, replication schemes can be surprisingly complicated. The primary reason is that the purpose of replication is to suppress unintended changes to the data caused by random decay. But decay suppression also complicates intended changes, since one must now update more than one copy, while being prepared for the possibility of a failure in the midst of that update. In addition, if updates are frequent, the protocols to perform update must not only be correct and robust, they must also be efficient. Since multiple replicas can usually be read and written concurrently, it is possible to take advantage of that possibility to enhance overall system performance. But performance enhancement can then become a complicating requirement of its own, one that interacts strongly with a requirement for strict consistency.

---

\(^*\)Letter from Thomas Jefferson to the publisher and historian Ebenezer Hazard, February 18, 1791. Library of Congress, The Thomas Jefferson Papers Series 1. General Correspondence. 1651-1827.

Replicated State Machines

Data replicas require a management plan. If the data is written exactly once and never again changed, the management plan can be fairly straightforward: make several copies, put them in different places so they will not all be subject to the same environmental faults, and develop algorithms for reading the data that can cope with loss of, disconnection from, and decay of data elements at some sites.

Unfortunately, most real world data need to be updated, at least occasionally, and update greatly complicates management of the replicas. Fortunately, there exists an easily-described, systematic technique to ensure correct management. Unfortunately, it is surprisingly hard to meet all the conditions needed to make it work.

The systematic technique is a sweeping simplification known as the replicated state machine. The idea is to identify the data with the state of a finite state machine whose inputs are the updates to be made to the data, and whose operation is to make the appropriate changes to the data, as illustrated in Figure \(\PageIndex{1}\) by maintaining identical data replicas, co-locating with each of those replicas a replica of the state machine, and sending the same inputs to each state machine. Since the state of a finite state machine is at all times determined by its prior state and its inputs, the data of the various replicas will, in principle, perfectly match one another.

Figure \(\PageIndex{1}\): Replicated state machines. If \(N\) identical state machines that all have the same prior state receive and perform the same update requests in the same order, then all \(N\) of the machines will enter the same new state.

The concept is sound, but four real-world considerations conspire to make this method harder than it looks:

1. All of the state machine replicas must receive the same inputs, in the same order. Agreeing on the values and order of the inputs at separated sites is known as achieving consensus. Achieving consensus among sites that do not have a common clock, that can crash independently, and that are separated by a best-effort communication network is a project in itself. Consensus has received much attention from theorists, who begin by defining its core essence, known as the consensus problem: to achieve agreement on a single binary value. There are various algorithms and protocols designed to solve this problem under specified conditions, as well as proofs that with certain kinds of failures consensus is impossible to reach. When conditions permit solving the core consensus problem, a designer can then apply bootstrapping to come to agreement on the complete set of values and order of inputs to a set of replicated state machines.
2. All of the data replicas (in Figure \(\PageIndex{1}\), the "prior state") must be identical. The problem is that random decay events can cause the data replicas to drift apart, and updates that occur when they have drifted can cause them to drift further apart. So there needs to be a plan to check for this drift and correct it. The mechanism that identifies such differences and corrects them is known as reconciliation.
3. The replicated state machines must also be identical. This requirement is harder to achieve than it might at first appear. Even if all the sites run copies of the same program, the operating environment surrounding that program may affect its behavior, and there can be transient faults that affect the operation of individual state machines differently. Since the result is again that the data replicas drift apart, the same reconciliation mechanism that fights decay may be able to handle this problem.
4. To the extent that the replicated state machines really are identical, they will contain identical implementation faults. Updates that cause the faults to produce errors in the data will damage all the replicas identically, and reconciliation can neither detect nor correct the errors.

The good news is that the replicated state machine scheme not only is systematic, but it lends itself to modularization. One module can implement the consensus-achieving algorithm; a second set of modules, the state machines, can perform the actual updates; and a third module responsible for reconciliation can periodically review the data replicas to verify that they are identical and, if necessary, initiate repairs to keep them that way.

Shortcuts to Meet More Modest Requirements

The replicated state machine method is systematic, elegant, and modular, but its implementation requirements are severe. At the other end of the spectrum, some applications can get along with a much simpler method: implement just a single state machine. The idea is to carry out all updates at one replica site, generating a new version of the database at that site, and then somehow bring the other replicas into line. The simplest, brute-force scheme is to send a copy of this new version of the data to each of the other replica sites, completely replacing their previous copies. This scheme is a particularly simple example of master/slave replication. One of the things that makes it simple is that there is no need for consultation among sites; the master decides what to do and the slaves just follow along.

The single state machine with brute-force copies works well if:

• The data need to be updated only occasionally.
• The database is small enough that it is practical to retransmit it in its entirety.
• There is no urgency to make updates available, so the master can accumulate updates and perform them in batches.
• The application can get along with temporary inconsistency among the various replicas. Requiring clients to read from the master replica is one way to mask the temporary inconsistency. On the other hand if, for improved performance, clients are allowed to read from any available replica, then during an update a client reading data from a replica that has received the update may receive different answers from another client reading data from a different replica to which the update hasn’t propagated yet.

This method is subject to data decay, just as is the replicated state machine, but the effects of decay are different. Undetected decay of the master replica can lead to a disaster in which the decay is propagated to the slave replicas. On the other hand, since update installs a complete new copy of the data at each slave site, it incidentally blows away any accumulated decay errors in slave replicas, so if update is frequent, it is usually not necessary to provide reconciliation. If updates are so infrequent that replica decay is a hazard, the master can simply do an occasional dummy update with unchanged data to reconcile the replicas.

The main defect of the single state machine is that even though data access can be fault-tolerant—if one replica goes down, the others may still available for reading—data update is not: if the primary site fails, no updates are possible until that failure is detected and repaired. Worse, if the primary site fails while in the middle of sending out an update, the replicas may remain inconsistent until the primary site recovers. This whole approach doesn't work well for some applications, such as a large database with a requirement for strict consistency and a performance goal that can be met only by allowing concurrent reading of the replicas.

Despite these problems, the simplicity is attractive, and in practice many designers try to get away with some variant of the single state machine method, typically tuned up with one or more enhancements:

• The master site can distribute just those parts of the database that changed (the updates are known as "deltas" or "diffs") to the replicas. Each replica site must then run an engine that can correctly update the database using the information in the deltas. This scheme moves back across the spectrum in the direction of the replicated state machine. Though it may produce a substantial performance gain, such a design can end up with the disadvantages of both the single and the replicated state machines.
• Devise methods to reduce the size of the time window during which replicas may appear inconsistent to reading clients. For example, the master could hold the new version of the database in a shadow copy, and ask the slave sites to do the same, until all replicas of the new version have been successfully distributed. Then, short messages can tell the slave sites to make the shadow file the active database. (This model should be familiar: a similar idea was used in the design of the two-phase commit protocol described in Chapter 3.)
• If the database is large, partition it into small regions, each of which can be updated independently. Section 4.4.7, below, explores this idea in more depth. (The Internet Domain Name System is for the most part managed as a large number of small, replicated partitions.)
• Assign a different master to each partition, to distribute the updating work more evenly and increase availability of update.
• Add fault tolerance for data update when a master site fails by using a consensus algorithm to choose a new master site.
• If the application is one in which the data is insensitive to the order of updates, implement a replicated state machine without a consensus algorithm. This idea can be useful if the only kind of update is to add new records to the data and the records are identified by their contents, rather than by their order of arrival. Members of a workgroup collaborating by email typically see messages from other group members this way. Different users may find that received messages appear in different orders, and may even occasionally see one member answer a question that another member apparently hasn’t yet asked, but if the email system is working correctly, eventually everyone sees every message.
• The master site can distribute just its update log to the replica sites. The replica sites can then run REDO on the log entries to bring their database copies up to date. Or, the replica site might just maintain a complete log replica rather than the database itself. In the case of a disaster at the master site, one of the log replicas can then be used to reconstruct the database.

This list just touches the surface. There seem to be an unlimited number of variations in application-dependent ways of doing replication.

Maintaining Data Integrity

In updating a replica, many things can go wrong: data records can be damaged or even completely lost track of in memory buffers of the sending or receiving systems, transmission can introduce errors, and operators or administrators can make blunders, to name just some of the added threats to data integrity. The durability mantra suggests imposing physical and administrative separation of replicas to make threats to their integrity more independent, but the threats still exist.

The obvious way to counter these threats to data integrity is to apply the method suggested in Section 3.8.1 to counter spontaneous data decay: plan to periodically compare replicas, doing so often enough that it is unlikely that all of the replicas have deteriorated. However, when replicas are not physically adjacent this obvious method has the drawback that bit-by-bit comparison requires transmission of a complete copy of the data from one replica site to another, an activity that can be time-consuming and possibly expensive.

An alternative and less costly method that can be equally effective is to calculate a witness of the contents of a replica and transmit just that witness from one site to another. The usual form for a witness is a hash value that is calculated over the content of the replica, thus attesting to that content. By choosing a good hash algorithm (for example, a cryptographic quality hash such as described in Sidebar 5.9.1) and making the witness sufficiently long, the probability that a damaged replica will have a hash value that matches the witness can be made arbitrarily small. A witness can thus stand in for a replica for purposes of confirming data integrity or detecting its loss.

The idea of using witnesses to confirm or detect loss of data integrity can be applied in many ways. We have already seen checksums used in communications, both for end-to-end integrity verification (Section 1.3.5) and in the link layer (Section 1.4.3); checksums can be thought of as weak witnesses. For another example of the use of witnesses, a file system might calculate a separate witness for each newly written file, and store a copy of the witness in the directory entry for the file. When later reading the file, the system can recalculate the hash and compare the result with the previously stored witness to verify the integrity of the data in the file. Two sites that are supposed to be maintaining replicas of the file system can verify that they are identical by exchanging and comparing lists of witnesses. In Chapter 5 we will see that by separately protecting a witness, one can also counter threats to data integrity that are posed by an adversary.

Replica Reading and Majorities

So far, we have explored various methods of creating replicas, but not how to use them. The simplest plan, with a master/slave system, is to direct all client read and write requests to the primary copy located at the master site, and treat the slave replicas exclusively as backups whose only use is to restore the integrity of a damaged master copy. What makes this plan simple is that the master site is in a good position to keep track of the ordering of read and write requests, and thus enforce a strict consistency specification such as the usual one for memory coherence: that a read should return the result of the most recent write.

A common enhancement to a replica system, intended to increase availability for read requests, is to allow reads to be directed to any replica, so that the data continues to be available even when the master site is down. In addition to improving availability, this enhancement may also have a performance advantage, since the several replicas can probably provide service to different clients at the same time. Unfortunately, the enhancement has the complication that there will be instants during update when the several replicas are not identical, so different readers may obtain different results, a violation of the strict consistency specification. To restore strict consistency, some mechanism that ensures before-or-after atomicity between reads and updates would be needed, and that before-or-after atomicity mechanism will probably erode some of the increased availability and performance.

Both the simple and the enhanced schemes consult only one replica site, so loss of data integrity, for example from decay, must be detected using just information local to that site, perhaps with the help of a witness stored at the replica site. Neither scheme takes advantage of the data content of the other replicas to verify integrity. A more expensive, but more reliable, way to verify integrity is for the client to also obtain a second copy (or a witness) from a different replica site. If the copy (or witness) from another site matches the data (or a just-calculated hash of the data) of the first site, confidence in the integrity of the data can be quite high. This idea can be carried further to obtain copies or witnesses from several of the replicas, and compare them. Even when there are disagreements, if a majority of the replicas or witnesses agree, the client can still accept the data with confidence, and might in addition report a need for reconciliation.

Some systems push the majority idea further by introducing the concept of a quorum. Rather than simply "more than half the replicas," one can define separate read and write quorums, \(Q_r\) and \(Q_w\), that have the property that \(Q_r + Q_w > N_{replicas}\). This scheme declares a write to be confirmed after writing to at least a write quorum, \(Q_w\), of replicas (while the system continues to try to propagate the write to the remaining replicas), and a read to be successful if at least a read quorum, \(Q_r\), agree on the data or witness value. By varying \(Q_r\) and \(Q_w\), one can configure such a system to bias availability in favor of either reads or writes in the face of multiple replica outages. In these terms, the enhanced availability scheme described above is one for which \(Q_w = N_{replicas}\) and \(Q_r = 1\).

Alternatively, one might run an \(N_{replicas} = 5\) system with a rule that requires that all updates be made to at least \(Q_w = 4\) of the replicas and that reads locate at least \(Q_r = 2\) replicas that agree. This choice biases availability modestly in favor of reading: a successful write requires that at least 4 of the 5 replicas be available, while a read will succeed if only 2 of the replicas are available and agree, and agreement of 2 is ensured if any 3 are available. Or, one might set \(Q_w = 2\) and \(Q_r = 4\). That configuration would allow someone doing an update to receive confirmation that the update has been accomplished if any two replicas are available for update, but reading would then have to wait at least until the update gets propagated to two more replicas. With this configuration, write availability should be high but read availability might be quite low.

In practice, quorums can actually be quite a bit more complicated. The algorithm as described enhances durability and allows adjusting read versus write availability, but it does not provide either before-or-after or all-or-nothing atomicity, both of which are likely to be required to maintain strict consistency if there is either write concurrency or a significant risk of system crashes. Consider, for example, the system for which \(N_{replicas} = 5\), \(Q_w = 4\), and \(Q_r = 2\). If an updater is at work and has successfully updated two of the replicas, one reader could read the two replicas already written by the updater while another reader might read two of the replicas that the updater hasn’t gotten to yet. Both readers would believe they had found a consistent set of replicas, but the read/write coherence specification has not been met. Similarly, with the same system parameters, if an updater crashes after updating two of replicas, a second updater might come along and begin updating a different two of the replicas and then crash. That scenario would leave a muddled set of replicas in which one reader could read the replicas written by the first updater while another reader might read the replicas written by the second updater.

Thus a practical quorum scheme requires some additional before-or-after atomicity mechanism that serializes writes and ensures that no write begins until the previous write has sufficiently propagated to ensure coherence. The complexity of the mechanism depends on the exact system configuration. If all reading and updating originates at a single site, a simple sequencer at that site can provide the needed atomicity. If read requests can come from many different sources but all updates originate at a single site, the updating site can associate a version number with each data update and reading sites can check the version numbers to ensure that they have read the newest consistent set. If updates can originate from many sites, a protocol that provides a distributed sequencer implementation might be used for atomicity. Performance maximization usually is another complicating consideration. The interested reader should consult the professional literature, which describes many (sometimes quite complex) schemes for providing serialization of quorum replica systems. All of these mechanisms are specialized solutions to the generic problem of achieving atomicity across multiple sites, which was discussed at the end of Chapter 3.

Backup

Probably the most widely used replication technique for durable storage that is based on a single state machine is to periodically make backup copies of a complete file system on an independent, removable medium such as magnetic tape, writable video disk (DVD), or removable hard disk. Since the medium is removable, one can make the copy locally and introduce geographic separation later. If a disk fails and must be replaced, its contents can be restored from the most recent removable medium replica. Removable media are relatively cheap, so it is not necessary to recycle previous backup copies immediately. Older backup copies can serve an additional purpose, as protection against human error by acting as archives of the data at various earlier times, allowing retrieval of old data values.

The major downside of this technique is that it may take quite a bit of time to make a complete backup copy of a large storage system. For this reason, refinements such as incremental backup (copy only files changed since the last backup) and partial backup (don’t copy files that can be easily reconstructed from other files) are often implemented. These techniques reduce the time spent making copies, but they introduce operational complexity, especially at restoration time.

A second problem is that if updates to the data are going on at the same time as backup copying, the backup copy may not be a snapshot at any single instant—it may show some results of a multi-file update but not others. If internal consistency is important, either updates must be deferred during backup or some other scheme, such as logging updates, must be devised. Since complexity also tends to reduce reliability, the designer must use caution when going in this direction.

It is worth repeating that the success of data replication depends on the independence of failures of the copies, and it can be difficult to assess correctly the amount of independence between replicas. To the extent that they are designed by the same designer and are modified by the same software, replicas may be subject to the same design or implementation faults. It is folk wisdom among system designers that the biggest hazard for a replicated system is replicated failures. For example, a programming error in a replicated state machine may cause all of the data replicas to become identically corrupted. In addition, there is more to achieving durable storage than just replication. Because a thread can fail at a time when some invariant on the data is not satisfied, additional techniques are needed to recover the data.

Complexity can also interfere with success of a backup system. Another piece of folk wisdom is that the more elaborate the backup system, the less likely that it actually works. Most experienced computer users can tell tales of the day that the disk crashed, and for some reason the backup copy did not include the most important files. (But the tale usually ends with a story that the owner of those files didn’t trust the backup system, and was able to restore those important files from an ad hoc copy he or she made independently.)

Partitioning Data

A quite different approach to tolerating failures of storage media is to simply partition the data, thereby making the system somewhat fail-soft. In a typical design, one would divide a large collection of data into several parts, each of about the same size, and place each part on a different physical device. Failure of any one of the devices then compromises availability of only one part of the entire set of data. For some applications this approach can be useful, easy to arrange and manage, easy to explain to users, and inexpensive. Another reason that partition is appealing is that access to storage is often a bottleneck. Partition can allow concurrent access to different parts of the data, an important consideration in high-performance applications such as popular Web servers.

Replication can be combined with partition. Each partition of the data might itself be replicated, with the replicas placed on different storage devices, and each storage device can contain replicas of several of the different partitions. This strategy ensures continued availability if any single storage device fails, and at the same time an appropriate choice of configuration can preserve the performance-enhancing feature of partition.
